linearray Viper-LA

Line Array speaker cabinet


linearray Viper-LA          linearray Viper-LA

Viper-LA general description

Features Viper-LA

  • 12" neodymium speaker (3"voice coil)
  • 2x compression driver 1.75"/45mm voice coil
  • 2x 1" planar wave guide device
  • horn directivity h90°/v10°
  • constant horn directivity
  • curving angles 0°-10° in 1° steps
  • 4-point rigging structure
  • 2 x Neutrik speakon 4-pin
  • speaker signal link function
  • perforated steel front grill powder coated
  • acoustic foam 4mm behind front grill
  • wood housing 15mm plywood
  • polyurea (PU) high scratch proof coating
  • optional regular painting black or white

Appliance Viper-LA

  • line array unit for mobile and touring PA
  • line array unit for fix installation

Application Viper-LA

  • live events, live entertainment
  • stadium broadcasting,
  • discotheque and mobile disco event
  • meeting halls broadcast system

extended system components

  • LB-3* subwoofer (1x18")
  • VB-218pro subwoofer (2x18")
  • VB-218 subwoofer (2x18")
    *with rigging hardware

linearray Viper-LA

linearray Viper-LA

linearray Viper-LA

linearray Viper-LA

linearray Viper-LA


Viper-LA specification
rated impedance
operation mode bi-amp
power handling capacity midrange AES/peak* 400W / 1600W*
power handling capacity HF AES/peak* 100W / 400W*
available frequency response** 58Hz-20kHz
max. sound pressure level*** 141dB
directivity (h x v) 90°/10°
midrange-transducer rated size 12"
midrange-transducer voice coil diameter 3" (76mm)
LF-transducer magnet structure neodymium
HF-compression driver rated size (VC) 2x1.75" (45mm)
HF-compression throat diameter 1"
HF-compression magnet structure neodymium
dimension w/h/d in mm 580/350/435
weight 17.2kg

* peak 10ms, with TD-8000 amplifier and Viper-LA max controller setup
** -10dB with Viper-LA FR controller setup
***1m free field, pink noise, crest factor 10dB, with TD-8000 and Viper-LA SPL bi-amp controller setup
****system vertical directivity depends on quantity and curving of Viper-LA cabinets

small variety of a wide range for bass cabinet extension

Bass LB-3


Bass B-18


Bass VB-218
